MELLANOX Infiniband Host Bus Adapter,1 X Pci Express 3.0 X16 56 Gbit/s 1 X Total Infiniband Port(s) Plug-in Card MCB193A-FCAT

Detail overview

Product Details:

Mellanox Mcb193a-fcat Infiniband Host Bus Adapter,1 X Pci Express 3.0 X16 56 Gbit/s 1 X Total Infiniband Port(s) Plug-in Card.

Specifications
Device Type: Host Bus Adapter
Form Factor : Plug-in Card
Interface (bus) Type : Pci Express 3.0 X16
Pci Specification Revision: Pcie 3.0
Connectivity Technology: Wired
Data Link Protocol : Infiniband
Data Transfer Rate : 56 Gbps
Capacity: I/o Channels : 16000000
Network / Transport Protocol: Tcp/ip, Udp/ip, Ipoib, Udapl, Smb.
Features: Auto-negotiation, Quality Of Service (qos), Rdma Support, Infiniband Fdr Link Support, Flexboot Technology, Extended Message-signaled Interrupts (msi-x)
Compliant Standards: Ibta 1.2.1
Expansion / Connectivity Interfaces : 1 X Infiniband Fdr
Compliant Standards : Rohs
Software / System Requirements Os Required : Novell Netware, Suse Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Compute Cluster Server 2003, Microsoft Windows Server 2008, Microsoft Windows Hpc Server 2008, Vmware Esx 5.1

Dimensions & Weight:
Depth : 5.6 In
Height : 2.7 In
