ASRock Z590 OC Formula Desktop Motherboard - Intel Chipset - Socket LGA-1200 - Intel Optane Memory Ready - Extended ATX - Celeron, Core i3, Core i5, Core i7, Core i9, Pentium Gold Processor Supported - 64 GB DDR4 SDRAM Maximum RAM - DIMM, UDIMM - 2 x Memo

ASRock Z590 OC Formula Desktop Motherboard - Intel Chipset - Socket LGA-1200 - Intel Optane Memory Ready - Extended ATX - Celeron, Core i3, Core i5, Core i7, Core i9, Pentium Gold Processor Supported - 64 GB DDR4 SDRAM Maximum RAM - DIMM, UDIMM - 2 x Memory Slots - Gigabit Ethernet - IEEE 802.11 a/b/g/n/ax - 8 x SATA Interfaces
Technical Specifications:
Chipset Manufacturer: Intel
Chipset Model: Z590
Total Processor Supported: 1
Processor Socket: Socket LGA-1200
Processor Supported: Celeron, Core i3, Core i5, Core i7, Core i9, Pentium Gold
Multi GPU Supported: CrossFireX
Number of Memory Slots: 2
Memory Form Factor: DIMM, UDIMM
Maximum Memory Supported: 64 GB
Memory Technology: DDR4 SDRAM
Memory Speed Supported: 6000 MHz, 5000 MHz, 3200 MHz, 2933 MHz
Intel Optane Memory Ready: Yes
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0, 1, 5, 10
Onboard Video: CPU Dependent Video
Audio Channels: 7.1
Bluetooth: Yes
Gigabit Ethernet: Yes
2.5Gigabit Ethernet: Yes
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11 a/b/g/n/ax
Number of Total Expansion Slots: 5
Total Number of PCI Express Slots: 5
Number of PCI Express x1 Slots: 2
Number of PCI Express x16 Slots: 3
Total Number of USB Ports: 8
Number of USB 3.2 Ports: 1
Number of USB 3.2 Gen 1 Ports: 4
Number of USB 3.2 Gen 2 Type-A Ports: 3
S/PDIF: Yes
Number of Network (RJ-45) Ports: 2
Number of SATA Interfaces: 8
Number of M.2 Interfaces: 4
Total Number of Onboard USB Ports: 9
Number of Onboard USB 2.0 Ports: 4
Number of Onboard USB 3.2 Ports: 5
Product Color: Matte Black
Form Factor: Extended ATX
Width: 12"
Depth: 10.5"
Brand Compatibility: Intel
