Black Box Serial Switchbox - 4 x Serial Port - TAA Compliant - TAA Compliance SW1046A

Black Box Serial Switchbox - 4 x Serial Port - TAA Compliant - TAA Compliance

Has an Ethernet network interface that can be used to control the switch port connection state, as well as monitor switch status via a web browser, telnet, or using SNMP

Technical Specifications:
Input Connector Type: Serial
Number of Serial Ports: 4
Height: 2.5"
Width: 6.3"
Depth: 8.1"
Weight (Approximate): 4 lb
Additional Information:

Data Rate Greater than 10 Mbps, Power Input: 100-240 VAC, 50-60 Hz, autosensing; Output: 5 VDC, Switching Speed Typical: 5 msec; Maximum: 10 msec

Connectors:

A/B switch ports: (3) DB9 F, Ethernet control port: (1) RJ-45 10BASE-T port for remote control interface, Serial control port: DB9 F, Remote control/status port: (1) 6-position terminal block, Power: (1) 2.1 x 5.5-mm power input

Certifications & Standards:

CE, FCC

Environmentally Friendly: Yes
Environmental Certification: RoHS, WEEE
Country of Origin: United States
TAA Compliant: Yes
