Dataram 64GB DDR4 SDRAM Memory Module - For Desktop PC, Server - 64 GB (1 x 64 GB) - DDR4-2933/PC4-23400 DDR4 SDRAM - CL21 - 1.20 V - ECC - 288-pin - LRDIMM DVM29L4T4/64G

Dataram 64GB DDR4 SDRAM Memory Module - For Desktop PC, Server - 64 GB (1 x 64 GB) - DDR4-2933/PC4-23400 DDR4 SDRAM - CL21 - 1.20 V - ECC - 288-pin - LRDIMM

DVM29L4T4/64G is a load-reduced 8Gx72 memory module, which conforms to JEDEC''s DDR4-2933, PC4-2933 standard. The assembly is Quad-Rank. Each rank is comprised of nine 4Gbx4 DDR4-2933 SDRAMs.One EEPROM is used for Serial Presence Detect and a Registering Clock Driver, with Address and Command Parity, is also used as well as data buffers to reduce the overall loading on the data bus.Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology.A thermal sensor accurately monitors the DIMM module and can prevent exceeding the maximum operating temperature of 95C.

Technical Specifications:
Memory Size: 64 GB
Memory Technology: DDR4 SDRAM
Memory Voltage: 1.20 V
Number of Modules: 1 x 64GB
Memory Speed: 2933 MHz
Memory Standard: DDR4-2933/PC4-23400
Error Checking: ECC
CAS Latency: CL21
Device Supported: Desktop PC, Server
Number of Pins: 288-pin
Form Factor: LRDIMM
Width: 1.2"
Length: 5.3"
