Infortrend EonServ 7012 NAS Storage System - 2 x Intel Xeon E5-2620 v4 Octa-core (8 Core) 2.10 GHz - 12 x HDD Supported - 12 x HDD Installed - 96 TB Installed HDD Capacity - 12 x SSD Supported - 32 GB RAM DDR4 SDRAM - 1 x 12Gb/s SAS Controller - RAID Supp

Infortrend EonServ 7012 NAS Storage System - 2 x Intel Xeon E5-2620 v4 Octa-core (8 Core) 2.10 GHz - 12 x HDD Supported - 12 x HDD Installed - 96 TB Installed HDD Capacity - 12 x SSD Supported - 32 GB RAM DDR4 SDRAM - 1 x 12Gb/s SAS Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60 - 12 x Total Bays - 12 x 2.5"/3.5" Bay - 7 x Total Slot(s) - 10 Gigabit Ethernet - 4 USB Port(s) - 2 USB 2.0 Port(s) - 2 USB 3.0 Port(s) - Network (RJ-45) - 1 SAS Port(s) External - 2U - Rack-mountable

EonServ 7000High performance enterprise storage servers integrated dual processors EonServ 7000 is Infortrend''s new generation hybrid server-storage designed to combine the best of both worlds. It provides enhanced server performance with reliability of Infortrend''s RAID storage data protection, massive capacity expansion, high availability, easy maintenance, and simple management to take the complexity out of IT administration for businesses of all scales.

Technical Specifications:
Number of Hard Drives Supported: 12
Number of Hard Drives Installed: 12
Total Hard Drive Capacity Installed: 96 TB
Number of Solid State Drive Supported: 12
Number of Solid State Drive Installed: No
Number of Processors Installed: 2
Processor Manufacturer: Intel
Processor Type: Xeon
Processor Model: E5-2620 v4
Processor Core: Octa-core (8 Core)
Processor Speed: 2.10 GHz
Standard Memory: 32 GB
Memory Technology: DDR4 SDRAM
Ethernet Technology: 10 Gigabit Ethernet
Number of Total Expansion Bays: 12
Number of 2.5"/3.5" Bays: 12
Number of Total Expansion Slots: 7
Expansion Slot Type: SFP+, PCI Express 3.0 x16, PCI Express 3.0 x8
Number of Controllers: 1
Controller Type: 12Gb/s SAS
RAID Supported: Yes
RAID Levels: 0, 1, 5, 6, 10, 50, 60
Drive Interface: Serial Attached SCSI (SAS)
Number of SAS Ports (External): 1
Total Number of USB Ports: 4
Number of USB 2.0 Ports: 2
Number of USB 3.0 Ports: 2
Network (RJ-45): Yes
Number of Power Supplies Installed: 2
Maximum Power Supply Wattage: 1200 W
Redundant Power Supply: Yes
Height: 3.5"
Width: 17.7"
Depth: 25.6"
Form Factor: Rack-mountable
Rack Height: 2U
Package Contents:

EonServ 7012 NAS Storage System, 1 x Rackmount Kit
