Omnitron Systems iConverter 2423-2-23 T1/E1 Multiplexer - 1 Gbit/s - 1 x RJ-45 2423-2-23

Omnitron Systems iConverter 2423-2-23 T1/E1 Multiplexer - 1 Gbit/s - 1 x RJ-45

The iConverter T1/E1 MUX/M multiplexes up to sixteen T1 or E1 circuits and one 10/100/1000 Ethernet service onto a fiber optic transport link, and features remotely managed testing and configuration capabilities.The iConverter T1/E1 MUX/M operates in a back-to-back configuration, and can be used in applications such as multiple T1/E1 extension, mobile backhaul and building-to-building PBX connectivity.The T1/E1 copper interfaces are available in 4, 8, 12 or 16 RJ-48 port configurations for balanced T1/E1 applications. Optional adapter cables are available to convert each RJ-48 interface to a BNC interface for unbalanced E1 transport applications.Additional hot-swappable 4-Port T1/E1 MUX modules can be installed to increase system capacity up to 16 T1/E1 ports maximum per 1U (1.75 inch) chassis.

Technical Specifications:
Management Port: Yes
Number of Network (RJ-45) Ports: 1
Number of SC Ports: 1
Connectivity Technology: Wired
Media Type Supported: Twisted Pair
Network Technology Supported: 10/100/1000Base-T
Maximum Data Transfer Rate: 1 Gbit/s
Number of Total Expansion Slots: 4
Form Factor: Rack-mountable
Rack Height: 1U
Height: 1.8"
Width: 17.2"
Depth: 9"
Weight (Approximate): 7.50 lb
Package Contents: iConverter 2423-2-23 T1/E1 Multiplexer, 2 x 4-Port T1/E1 MUX Module, 1 x 48VDC Power Supply
Country of Origin: United States
