SIIG Full HD HDMI Extender with IR - 164ft Over Cat5e/6 - 1080p 60Hz HDMI Audio Video Extender CE-H26111-S1

SIIG Full HD HDMI Extender with IR - 164ft Over Cat5e/6 - 1080p 60Hz HDMI Audio Video Extender

Extends HDMI audio/video signals up to 164ft over Cat5e/6 cable. Supports 480i/480p/720p/1080i/1080p at 60Hz resolutions Extends HDMI signals up to 164ft (50m) via a single cost effective CAT5e/6 networking cable, ideal for home theater, conference room or other audio/video applications that require remote location setup. Note: Extension over 100ft requires 100% copper Cat6 cable Delivers high-quality video/audio transmission without compression for optimal performance, supports video resolution up to 1080p@60Hz (Full HD), and 2-channel stereo audio, compatible with HDCP compliant devices and content, HDMI 1.3 and HDCP 1.2 compliant IR control allows your HDMI source device to recognize remote commands, you can control the HDMI source device from the remote location of your display device with the included IR cables that transmit signals over Cat cable Premium metal housing offers excellent heat dissipation, enhances durability, and minimizes EMI/RF interference for long life and dependable performance Easy installation, no driver installation is required, integrated surface mounting bracket allows secure placement Notes: A good quality Cat5e/6 cable is essential in delivering quality content. Cat6 is recommended over Cat5e STP (Shielded Twisted Pair) cabling is recommended for cable runs over 50ft This extender pair (TX + RX) is point-to-point connection, it does not work through routers or switches

Warning: Reproductive Harm - www.P65Warnings.ca.gov.

Technical Specifications:
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 164.04 ft
Graphics Modes: Full HD
Maximum Video Resolution: 1920 x 1080
Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
Number of Network (RJ-45) Ports: 2
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 6
Product Color: Black
Transmitter Height: 0.97"
Transmitter Width: 2.60"
Transmitter Depth: 2.80"
Receiver Height: 0.97"
Receiver Width: 2.60"
Receiver Depth: 2.80"
Transmitter Weight (Approximate): 3.04 oz
Receiver Weight (Approximate): 2.88 oz
Package Contents:

1 x Transmitter Unit, 1 x Receiver Unit, 1 x IR Blaster Cable, 1 x IR Receiver Cable, 2 x Power Adapter, User Reference Guide

Environmentally Friendly: Yes
Environmental Certification: RoHS
Country of Origin: China
