Tripp Lite HDBaseT HDMI Over Cat5e Cat6 Cat6a Extender Kit w/ Ethernet, Serial and IR Control 150m 500ft - 1 Input Device - 1 Output Device - 500 ft RangeNetwork (RJ-45) - 1 x HDMI In - 1 x HDMI Out - Serial Port - Full HD - 1920 x 1080 - Twisted Pair - C

Tripp Lite HDBaseT HDMI Over Cat5e Cat6 Cat6a Extender Kit w/ Ethernet, Serial and IR Control 150m 500ft - 1 Input Device - 1 Output Device - 500 ft RangeNetwork (RJ-45) - 1 x HDMI In - 1 x HDMI Out - Serial Port - Full HD - 1920 x 1080 - Twisted Pair - Category 6a - TAA Compliance

The BHDBT-K-E3SI-ER HDBaseT HDMI over Cat5e/6/6a Extender Kit extends uncompressed HDMI audio and video, RS-232 serial and IR remote control signals up to 500 feet over a single Cat5e/6/6a cable, including a 1920 x 1080(1080p) signal @ 60 Hz.In addition to HDMI, RS-232 and IR signals, this extender kit features three built-in 10/100 Ethernet ports on both the transmitter and receiver units. This allows connected devices, such as a Blu-ray™ player, cable/satellite box, and HDTV, to communicate with each other and access online content via LAN.You can also control RS-232 serial devices, such as touchscreen displays or scanners, at baud rates up to 115 Kbps. The two-way IR remote control feature(@ 39 KHz) lets you control your Blu-ray player using its remote when at the remote monitor or control your remote monitor using its remote when at the Blu-ray player. Locking HDMI ports(ideal for use with Tripp Lite''s P569-006-LOCK high-speed HDMI cables with locking connectors) on both the transmitter and receiver prevent cables from coming loose or undone, ensuring an intact signal. The plug-and-play BHDBT-K-E3SI-ER supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD audio, as well as 3D video, EDID and HDCP.

Technical Specifications:
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 500 ft
Graphics Modes: Full HD
Maximum Video Resolution: 1920 x 1080
Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
Serial Port: Yes
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 6a
Package Contents:

Transmitter Unit, Receiver Unit, IR-IN Cable, IR-OUT Cable, 2 x External power supplies (Input: 100-240V, 50/60 Hz, 1A; Output: 5V, 3A), Mounting Hardware, Owner's Manual

Environmentally Friendly: Yes
Environmental Certification: RoHS
Country of Origin: Taiwan
TAA Compliant: Yes
